深圳市格雷创科技有限公司一级经销优势供应芬兰DELCON固态继电器，公司从欧洲直接进口，绕过国外及国内层层代理，价格实惠，货期快，如需要采购Finland（芬兰）DELCON（德尔康）固态继电器价格、货期、技术参数、应用及厂商等信息,可立即联系我们，电话：0755-23000861，手机及微信：13713950680、15766208408，咨询请添加或点击企业QQ：4006380310(若此企业QQ号无法添加，请添加1429311537)，传真：0755-22704880，邮件：cs11@gchane.com，微信号:15766208408。







    芬兰DELCON德尔康公司是从专业从事固态继电器研发、制造的公司；DELCON德尔康固态继电器已通过UL、CE等国际IEC认证，作为工业控制接口继电器广泛应用于各种工业过程控制领域。









        DELCON德尔康固态继电器分为交流输入、交流输出、直流输入、直流输出系列。









 DELCON德尔康固态继电器的优势：

u  4000V隔离阻抗；

u  采用独特的脉冲变压器耦合技术；

u  信号线可长达1.5km，且不需屏蔽；

u  速度快、无触点、寿命长、无火花、耐腐蚀、与控制器及控制电路接口方便连接；

u  其内置电容抑制、RC回路瞬时电压抑制、电流电压滞后等环节，保证了继电器的通断准确、可靠，不会发生无法通断、误动作、通断震颤等情况；

u  可控制电压范围从0-265VAC或0-300VDC，有效电流从0-3A，亦有4A/10A/15A特殊电流要求的产品；



    由于DELCON德尔康固态继电器的独特技术和优越的品质使它成为成为世界上最可靠的固态继电器之一，每只固态继电器在封装前和封装后都经过严格的测试，所能承受的最大浪涌电流可达90A，寿命更是长达15-25年以上； 100%的测试让你可完全放心的在-25℃至+70℃环境下使用DELCON德尔康固态继电器，适合应用于非常严酷的工业环境。



产品图片：

 DELCON德尔康固态继电器常见型号有：

         编号                                描述

1       SDI 24N                Input Plug-in NPN Direct Connection，LED

2       SDI 24P                Input Plug-in NPN Direct Connection，LED

3       SDO 24                Input Plug-in NPN Direct Connection，LED

4       SLI 120CH           Input Plug-in relay 120 VAC ，transient Protection

5       SLI 120CR           Input Plug-in relay 120VAC

6       SLI 120CRI                Input Plug-in relay 120VAC,Normally Closed

7       SLI 120CRP              Input Plug-in relay 120VAC,proxy

8       SLI 120CRSN           Input DIN-rail relay 120VAC

9       SLI 125CH                Input Plug-in relay 125VDC ，transient Protection

10     SLI 125CR                Input Plug-in relay 125VDC

11     SLI 125CRI               Input Plug-in relay 120VDC,Normally Closed

12     SLI 12CR                  Input Plug-in relay 12VDC

13     SLI 12CRI                  Input Plug-in relay 12 VDC,Normally Closed

14     SLI 230CH                Input Plug-in relay 230VAC ，Transient Protection

15     SLI 230CHSN          Input DIN-rail relay 230VAC ，Transient Protection

16     SLI 230CR               Input Plug-in relay 230VAC

17     SLI 230CRI              Input Plug-in relay 230VAC,Normally Closed

18     SLI 230CRP            Input Plug-in relay 230VAC,Proxy

19     SLI 230RPS            Input DIN-rail relay 230VAC,Proxy

20     SLI 230CRPSN      Input DIN-rail relay 230VAC,Proxy,new socket

21     SLI 230CRR            Input Plug-in relay 230VAC,Current Limiting Secondary

22     SLI 230CRSN         Input DIN-rail relay 230VAC

23     SLI 24CR                 Input Plug-in relay 24 VDC

24     SLI 24CRF              Input Plug-in relay 24 VDC,fast

25     SLI 24CRI                Input Plug-in relay 24 VDC,Normally Closed

26     SLI 24CRL             Input Plug-in relay 24 VDC,Increased Input Current

27     SLI 24CRSN          Input DIN-rail relay 24 VDC

28     SLI 250CH             Input Plug-in relay 250VDC ，Transient Protection

29     SLI 250CR             Input Plug-in relay 250VDC

30     SLI 250CRI            Input Plug-in relay 250VDC,Normally Closed

31     SLI 25CR               Input Plug-in relay 24 VAC

32     SLI 25CRI             Input Plug-in relay 24 VDC,Normally Closed

33     SLI 380CRS       Input DIN-rail relay 380/400 VAC

34     SLI 48CR            Input Plug-in relay 48…60 VDC

35     SLI 48CRI           Input Plug-in relay 48 VDC,Normally Closed

36     SLI 49CR            Input Plug-in relay 48…60 VAC

37     SLI 49CRI           Input Plug-in relay 48 VAC,Normally Closed

38     ABI                      PLC Adapter for Allen Bradley PLC-5(Input)

39     ABIV                   PLC Adapter for Allen Bradley PLC-5(NPN Input)

40     ABO                    PLC Adapter for Allen Bradley PLC-5(NPN Output)

41     CAS 16AD         Cable Adapter for 16 DIN-rail Relays

42     CAS 16ADP       Cable Adapter for 16 DIN-rail Relays Test Buttons

43     CAS 16BD          Cable Adapter for 16 DIN-rail Relays

44     CAS 16BDP       Cable Adapter for 16 DIN-rail Relays Test Buttons

45     DSTD190IO32    Adapter for ABB unit DSTD190

46     FBPB16O16I       Profibus DP Slave Station

47     FC10-50               Flat Cable Harness 50 cm,basic length and price

48     FC10-XXX           Price for each extra 50cm,order with code FC10-measure of length

49     FC20-050            Flat Cable Harness 50 cm,basic length and price

50     FC20-XXX          Price for each extra 50cm,order with code FC20-measure of length

51     FCA 16I               Field Cable to Flat Cable Adapter,16 Inputs,1…16

52     FCA 16I-2            Field Cable to Flat Cable Adapter,16 Inputs,17…32

53     FCA 16N/P          NPN to PNP Converter 16 Channels

54     FCA 16N/P-2       NPN to PNP Converter 16 Channels 2 wire

55     FCA 16P/N          PNP to NPN Converter 16 Channels

56     FCA 16TB            Field Cable to Flat Cable Adapter with LEDs

57     FIO16                    Adapter for Fanuc Field Control

58     GLI 24CR              Input Relay 24 VDC GL-series

59     GLI 120CRP          Input Relay 120 VAC GL-series,Proxy

60     GLI 230CRP          Input Relay 230 VAC GL-series,Proxy

61     GLO 5CR              Ouput Relay 5 VDC/60 VDC 3 A GL-series

62     GLO 5TR               Ouput Relay 5 VDC/240 VAC 2,5 A GL-series

63     JUMPER 16-13          Chaining Jumper 16 Pin/13 mm

64     LPS12S                  Load Polarity Switch 12 VDC/24 VDC 10A

65     LPS24LS                Load Polarity Switch 24 VDC/24 VDC 10A

66     LPS24S                  Load Polarity Switch 24 VDC/24 VDC 10A

67     M-81CL                  PLC Adapter for Mitsubishi Meisec A2C

68     M-81CR                 PLC Adapter for Mitsubishi Meisec A2C

69     M82IO                   PLC Adapter for Mitsubishi Meisec A1S(3mm Screws)

70     M82IO2.5             PLC Adapter for Mitsubishi Meisec A1S(2,5mm Screws)

71     M-AX81               PLC Adapter for Mitsubishi Meisec A

72     M-AY81                PLC Adapter for Mitsubishi Meisec A

73     MB8BIP                Mounting Base PNP for 8 Input Relays Test Buttons

74     MB8BIPE              Extension Mounting Base PNP for 8 Input Relays Test Buttons

75     SLO 120CRA         Output Plug-in Relay 120 VDC/0…250 VDC 1,8A

76     SLO 120CRA4      Output Plug-in Relay 120 VDC/0…250 VDC 4A

77     SLO 12CR             Output Plug-in Relay 12 VDC/0…60 VDC 3A

78     SLO 12CRA          Output Plug-in Relay 12 VDC/0…250 VDC 1,8A

79     SLO 12CRX          Output Plug-in Relay 12 VDC/0…24 VDC 10A

80     SLO 220CRA        Output Plug-in Relay 220 VDC/0…250 VDC 1,8A

81     SLO 220CRA4      Output Plug-in Relay 220 VDC/0…250 VDC 4A

82     SLO 24CL              Output Plug-in Relay 24 VDC 2 mA/0…60 VDC 3A

83     SLO 24CR              Output Plug-in Relay 24 VDC/0…60 VDC 3A

84     SLO 24CRA           Output Plug-in Relay 24 VDC/0…250 VDC 1,8A

85     SLO 24CRA4         Output Plug-in Relay 24 VDC/0…250 VDC 4 A

86     SLO 24CRASN      Output DIN-rail Relay 24 VDC/0…250 VDC 1,8 A

87     SLO 24CRSN         Output DIN-rail Relay 24 VDC/0…60 VDC 3A

88     SLO 24CRX            Output Plug-in Relay 24 VDC/0…24 VDC 10A

89     SLO 24CRXSN       Output DIN-rail Relay 24 VDC/0…24 VDC 10A

90     SLO 24IRA               Output Plug-in Relay 24 VDC/0…240 VDC 1,2 A

91     SLO 24IRASN          Output DIN-rail Relay 24 VDC/0…240 VDC 1,2 A

92     SLO 24TH                 Output Plug-in Relay 24 VDC/0…240 VDC 3 A,Snubber

93     SLO 24THSN          Output DIN-rail Relay 24 VDC/0…240 VDC 3 A,Snubber

94     SLO 24TL                Output Plug-in Relay 24 VDC 2 mA/0…240 VAC 3 A

95     SLO 24TR               Output Plug-in Relay 24 VDC/0…240 VAC 3 A

96     SLO 24TRA            Output Plug-in Relay 24 VDC/0…240 VAC 2,5 A,for motor loads

97     SLO 24TRS            Output DIN-rail Relay 24 VDC/0…240 VDC 3 A

98     SLO 24TRSN         Output DIN-rail Relay 24 VDC/0…240 VDC 3 A,New Socket

99     SLO 48CRA          Output Plug-in Relay 48 VDC/0…250 VAC 1,8 A

100  SLO 48CRA4        Output Plug-in Relay 48 VDC/0…250 VAC 4 A

101  SLO 5CR               Output Plug-in Relay 5 VDC/0…60 VAC 3 A

102  SLO 5CRA            Output Plug-in Relay 5 VDC/0…250 VDC 1,8 A

103  SLO 5CRX            Output Plug-in Relay 5 VDC/0…24 VDC 10 A

104  SLO 5IRA             Output Plug-in Relay 5 VDC/0…240 VAC 1,2 A

105  SLO 5TR              Output Plug-in Relay 5 VDC/0…240 VAC 3 A

106  SLO A120TR       Output Plug-in Relay 120 VAC/0…240 VAC 1 A

107  SLO A230TR      Output Plug-in Relay 230 VAC/0…240 VAC 1 A

108  SLO P120TR      Output Plug-in Relay 120 VAC/0…240 VAC 3 A

109  SLO P230TR      Output Plug-in Relay 230 VAC/0…240 VAC 1,5 A

110  SRO 24B             Output Plug-in Mechanical Relay 24 VDC/0…240 VAC 3(6)A NC

111  SRO 24BSN       Output DIN-rail Mechanical Relay 24 VDC/0…240 VAC 3(6)A NC









其它配件如，Adapters适配器、Cables电缆、Motor control马达、PCB Sockets印刷电路板插座、Jumper跨接器、Converters转换器。

有任何问题及需求，请无需犹豫，直接联系我们。
